DOLL NEXT T3P-S3FS25

Technical Specifications + Features

  • Gross weight: 61,000 kg
  • Payload: approx. 44,500 kg
  • Axle load: 36,000 kg
  • Braking System: 12-ton drum brakes
  • Overall Length: 14,930 mm
  • Length (low-bed + Telescoping): 7,500 + 5,700 mm
  • Vehicle width: 2,550 mm / 2,750 mm
  • Loading height (loaded): 300 mm
  • Wheelbase: 1,360 mm / 1,510 mm

Retractable gooseneck

Hot-dip galvanized & stainless steel fittings

Smooth telescoping

High-quality fine-grained steel

3 Axles

High-quality coating

Do you need a high-performance low-bed trailer for heavy loads? We’ll configure the T3P exactly to your specifications.

Contact Us

Vehicle Inquiry

Request information about this vehicle now and receive a custom quote.
Made in Germany. Since 1878.

Many manufacturers talk about quality and a long service life. We actually deliver it.

With each new vehicle generation, we raise the bar a little higher – to achieve things that our competitors have not. True DOLL quality is all about usefulness; it's about satisfaction, being ahead of your game, taking pride in what you do. And it's about reliability and safety. Our quality sets the standard – mile after mile, on any terrain.
Gooseneck of the DOLL drop-down bed X with ramp shelf and non-slip rungs

Enhanced safety and ergonomics.

This is ensured by an optimized multi-clutch system, a practical Ramp deposit, and non-slip rungs on the Gooseneck.

Lashing of loads with the market-leading load securing concept on the DOLL drop deck X

Secured properly

DOLL offers a market-leading load-securing system with numerous tie-down points and stanchion pockets. How does it work? It’s simple and safe.

Full LED lighting at the rear.

With dynamic turn signals and flashing side marker lights for maximum safety on the road.

Minimum loading height: 300 mm

Thanks to a suspension travel of 600 mm (-70 mm / 530 mm), you benefit from maximum ground clearance.

Interested?

Got questions about equipment, or need more information? Don’t hesitate to contact our expert vehicle advisers:

Telephone: +49 7804 49-530
E-mail: schwer@doll.eu

Vehicle request

Send us your request to receive a personalised offer for this vehicle.

Intelligente Assistenz- und elektronische Steuerungssysteme

DOLL tronic: Intelligent Control Assistant

Behind the rugged keypads at the stern and on the gooseneck lies DOLL tronic—an intelligent CAN bus-based control and operating system. With its sophisticated sensor technology, it enables simple and safe operation of the gooseneck, Steering, and driving level.

DOLL connect: It's in your hands

With the help of the DOLL connect trailer management system and the smart Radio remote control, you can perform operation and Monitoring of all of your low-bed trailer functions in one place.

DOLL EEP: On the right track.

The EEP alignment system determines the correct steering angle for the axles. All you have to do is press a button on your Radio remote control—the rest happens automatically. Whether you're driving straight or turning!

Achstechnologien von heute und morgen

DOLL tera

The most rugged axle for use in harsh off-road conditions and extremely challenging terrain.
